Fault tree analysis template | Download format | FTA with Example:
Hi Readers! Today we will discuss on FTA. And also we have prepared some templates/formats considering with some situations. You can download the same templates from the below links. FTA (Fault tree analysis template) was developed by H.A Watson at Bell Laboratory in 1962. Fault tree analysis is generally used to analyze the undesired state of a system through Boolean algebra. This is commonly applicable in the fields of the Nuclear power sector, Chemical manufacturing and service sector, Pharmaceutical, Petrochemical, Aerospace, and other high-hazard industries but now it has become a popular diagram that is being used in almost all types of organizations or sectors.
DOWNLOAD –Fault Tree Analysis Sample Template.
As we know, if any incidents occur (may be due to high-risk factors or particular system level failure) in a high-hazard factory may lead to a high Severity score in health, environment, and safety concerns. So here we will explain the FTA in detail with EHS-related Examples.
FTA Event and Gate Symbols:
Frequently used gates are “OR gate” & “AND gate”.
You could also like to read our other articles:
5W2H Analysis Example |Download 5W2H Format.
5W1H Analysis Example |Download Template.
7 principles of QMS | Quality Management Principles.
Risk identification tools and techniques |Download Format.
SPC Format |DOWNLOAD Excel Template of SPC Study
Logic of “OR-Gate” & “AND-Gate”:
The output occurs if any input occurs. In the above figure you can see there is I/P-1 and I/P-2 in Or-Gate, The output of OR-gate will occur when any one of among two inputs will occurs. But in the case of AND-gate, the output will occur when both the input (I/P-1 & I/P-2) will occur.
Example: AFT of High Pollution:
